Increase your BBiQ® with CROSSRAY®
The smarter, easier way to cook

+

2 piece upper level cooking area +

+

High intensity infrared burner 13MJ/hr each +

+

Easy to access drain tray+

+

LED Illuminated control knobs +

+

Electronic ignition for simple burner start-up+

+

High grade 304 stainless steel construction +

+

Extremely solid construction and easy gas bottle access (trolley version only)+

High intensity infrared burner 11MJ/hr each +

4-burner
Trolley BBQ

(Model TCS4PL)

Dimensions:
1685mm W x 505mm D x 1255mm H (1495mm H with lid open)
5382cm2 cooking area
Materials:
+ 304 Stainless Steel front and rear body panels, lid, side shelves and
trolley doors.
+ Die cast aluminium side and end panels.
+ 4 x surface combustion infrared burners, capacity of 13 MJ/hr each.

4-burner
In-Built BBQ

(Model TCS4FL)

Dimensions:
915mm W x 505mm D x 560mm H (800mm H with lid open)
5382cm2 cooking area
Materials:
+ 304 Stainless Steel front and rear body panels, lid, side shelves and trolley doors.
+ Die cast aluminium side and end panels.
+ 4 x surface combustion infrared burners, capacity of 13 MJ/hr each.

2-burner
Trolley BBQ

(Model TCS2PL)

Dimensions:
1405mm W x 505mm D x 1255mm H (1495mm H with lid open)
3556cm2 cooking area
Materials:
+ 304 Stainless Steel front and rear body panels, lid, side shelves and trolley doors.
+ Die cast aluminium side and end panels.
+ 2 x surface combustion infrared burners, capacity of 13 MJ/hr each.

2-burner
In-Built BBQ

(Model TCS2FL)

Dimensions:
635mm W x 505mm D x 560mm H (800mm H with lid open)
3556cm2 cooking area
Materials:
+ 304 Stainless Steel front and rear body panels, lid, side shelves and trolley doors.
+ Die cast aluminium side and end panels.
+ 2 x surface combustion infrared burners, capacity of 13 MJ/hr each.

Accessories

+ Hot plate, black enamel
TCS4AC-001

+ Natural Gas Conversion Kit
TCS4AC-003

+ Outdoor vinyl cover for 2 & 4 burner trolley models
TCS4AC-002 (4B)
TCSAC-005 (2B)

+ Outdoor Vinyl cover for 2 & 4 burner in-built
TCS4AC-004 (4B)
TCSAC-006 (2B)

+ Rotisserie Kit for 2 & 4 burner models
TCS4AC-008 (4B)
TCS4AC-007 (2B)

All CROSSRAY BBQ’s come with grill plates as standard
